Criterion® CM-600

Medium center, high speed end load cartoner for small-medium formats (Up to 600 cpm)

Basic Info

  • TECHNOLOGY: Cartoning & Box Filling
  • INDUSTRY: Food, Home Care, Tea & Coffee
  • SEGMENT: Salt, Sugar & Spices, Laundry Care, Coffee, Other Tea & Coffee, Tea
CONTACT US
AFTER SALES SERVICE

Detailed Info

SHOW MORE
Footprint
Machine depth (mm)2000
Machine height (mm)2130
Machine length (mm)9000
Machine weight (kg)6500
Other technical features
Insertion modeEnd Load/Side Load
Performance
Operating modeContinuous
Product changeovern/a
Size changeover20 - 30 min (3-D changeover)
More Information
Other infoDesigned with a high degree of flexibility to accommodate your ever changing product and brand trends in the marketplace, and at a lower cost to you. Direct or Air Frame Carton Opening. Machine Centers: 4.5", 6", 7.5", 9"
Packaging range
Max pack height (mm)203
Min pack height (mm)89
Max pack length (mm)203
Min pack length (mm)51
Max pack width (mm)108
Min pack width (mm)25
Packaging features
Packaging closingGlue
Packaging materialPaperboard
Packaging orientationHorizontal
Packaging TypePrefolded Carton
Packaging typeCarton box
Value proposition
Value propositionPerformance
Attached Files
Criterion CM-600 BrochureDOWNLOAD
Video
Criterion CM-600WATCH
